MFCD14584820 molecular structure
click picture or here to close

methyl 5-nitro-2-[(propan-2-yl)amino]benzoate

ChemBase ID: 50999
Molecular Formular: C11H14N2O4
Molecular Mass: 238.23986
Monoisotopic Mass: 238.09535694
SMILES and InChIs

SMILES:
c1(c(NC(C)C)ccc([N+](=O)[O-])c1)C(=O)OC
Canonical SMILES:
COC(=O)c1cc(ccc1NC(C)C)[N+](=O)[O-]
InChI:
InChI=1S/C11H14N2O4/c1-7(2)12-10-5-4-8(13(15)16)6-9(10)11(14)17-3/h4-7,12H,1-3H3
InChIKey:
LQCMEDRULJWVFO-UHFFFAOYSA-N

Cite this record

CBID:50999 http://www.chembase.cn/molecule-50999.html

Collapse All Expand All

NAMES AND DATABASE IDS

NAMES AND DATABASE IDS

Names Database IDs
IUPAC name
methyl 5-nitro-2-[(propan-2-yl)amino]benzoate
IUPAC Traditional name
methyl 2-(isopropylamino)-5-nitrobenzoate
Synonyms
Methyl 2-(isopropylamino)-5-nitrobenzenecarboxylate
MDL Number
MFCD14584820
PubChem SID
162055762
PubChem CID
50853180

DATA SOURCES

DATA SOURCES

All Sources Commercial Sources Non-commercial Sources
Data Source Data ID
PubChem 50853180 external link

CALCULATED PROPERTIES

CALCULATED PROPERTIES

JChem
Acid pKa 13.067668  H Acceptors 4
H Donor 1  LogD (pH = 5.5) 2.812868
LogD (pH = 7.4) 2.812868  Log P 2.812868
Molar Refractivity 64.7692 cm3 Polarizability 23.339144 Å3
Polar Surface Area 84.15 Å2 Rotatable Bonds 5
Lipinski's Rule of Five true

PROPERTIES

PROPERTIES

Physical Property Safety Information Product Information Bioassay(PubChem)
Melting Point
104 - 106 °C expand Show data source
104-106°C expand Show data source
Storage Warning
IRRITANT expand Show data source
MSDS Link
Download expand Show data source
TSCA Listed
false expand Show data source
Purity
>95% expand Show data source
