162259040 molecular structure
click picture or here to close

sulfuric acid methyl 2-[2-chloro(2H4)phenyl]-2-{4H,5H,6H,7H-thieno[3,2-c]pyridin-5-yl}acetate

ChemBase ID: 164906
Molecular Formular: C16H18ClNO6S2
Molecular Mass: 419.90022
Monoisotopic Mass: 419.02640698
SMILES and InChIs

SMILES:
C1c2c(CCN1C(c1c(cccc1)Cl)C(=O)OC)scc2.S(=O)(=O)(O)O
Canonical SMILES:
OS(=O)(=O)O.COC(=O)C(c1ccccc1Cl)N1CCc2c(C1)ccs2
InChI:
InChI=1S/C16H16ClNO2S.H2O4S/c1-20-16(19)15(12-4-2-3-5-13(12)17)18-8-6-14-11(10-18)7-9-21-14;1-5(2,3)4/h2-5,7,9,15H,6,8,10H2,1H3;(H2,1,2,3,4)
InChIKey:
FDEODCTUSIWGLK-UHFFFAOYSA-N

Cite this record

CBID:164906 http://www.chembase.cn/molecule-164906.html

Collapse All Expand All

NAMES AND DATABASE IDS

NAMES AND DATABASE IDS

Names Database IDs
IUPAC name
sulfuric acid methyl 2-[2-chloro(2H4)phenyl]-2-{4H,5H,6H,7H-thieno[3,2-c]pyridin-5-yl}acetate
IUPAC Traditional name
sulfuric acid methyl 2-[2-chloro(2H4)phenyl]-2-{4H,6H,7H-thieno[3,2-c]pyridin-5-yl}acetate
Synonyms
α-(2-Chlorophenyl-d4)-6,7-dihydro-thieno[3,2-c]pyridine-5(4H)-acetic Acid Methyl Ester Sulfate
(+/-)-Clopidogrel-d4 Bisulfate
rac Clopidogrel-d4 Hydrogen Sulfate
PubChem SID
162259040
PubChem CID
45038698

DATA SOURCES

DATA SOURCES

All Sources Commercial Sources Non-commercial Sources
Data Source Data ID
TRC C587252 external link Add to cart
PubChem 45038698 external link
Data Source Data ID Price
TRC
C587252 external link Add to cart Please log in.
Data Source Data ID
PubChem 45038698 external link

CALCULATED PROPERTIES

CALCULATED PROPERTIES

JChem
H Acceptors H Donor
LogD (pH = 5.5) 3.875259  LogD (pH = 7.4) 4.029398
Log P 4.031764  Molar Refractivity 84.927 cm3
Polarizability 32.99487 Å3 Polar Surface Area 29.54 Å2
Rotatable Bonds Lipinski's Rule of Five true

PROPERTIES

PROPERTIES

Physical Property Safety Information Product Information Bioassay(PubChem)
Solubility
Methanol expand Show data source
Water expand Show data source
Apperance
White Solid expand Show data source
Melting Point
209-211°C expand Show data source
Storage Condition
-20°C Freezer expand Show data source
MSDS Link
Download expand Show data source
Certificate of Analysis
Download expand Show data source

DETAILS

DETAILS

TRC TRC
Toronto Research Chemicals - C587252 external link
Labelled Clopridogrel, an antithrombotic.A representative lot was: 4.2% d3, 0.07% d2, 0.0005% d1 and no d0 were detected.

REFERENCES

REFERENCES

From Suppliers Google Scholar IconGoogle Scholar PubMed iconPubMed Google Books IconGoogle Books
  • • Mills, D.C.B., et al.: Arterioscler. Thromb., 12, 430 (1992)
  • • Feuerstein, G., et al.: Exp. Opin. Invest. Drugs, 4, 425 (1995)
